SpeedyFiberTX 1-Pack 100 Feet 12 Fiber Low Loss Non-Pinned MPO to MPO Fiber Trunk Cable, Type-B, OM3 Corning ClearCurve Fiber, Fire Retardant Plenum Cable Jacket | MTP Compatible
Product details
| Management number | 212174457 | Release Date | 2026/04/06 | List Price | $40.00 | Model Number | 212174457 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
SpeedyFiberTX – 12 Fiber Low Loss Non-Pinned MPO to MPO Trunk Cable, Type-B Polarity, Multimode OM3 Corning ClearCurve FiberSpecifications Insertion Loss ≤ 0.35 (dB) Return Loss ≥ 20 (dB) Operating Temperature -10°C to +70°C Operating Wavelength 850nm and 1300nm 10G Ethernet Distance 300m at 850nm 40/100G Ethernet Distance 100m at 850nm Compliance UL, CE, IEC, TIA, RoHSFeatures and BenefitsLightweight 3.0mm UL Certified Fire Retardant Plenum OFNP Cable JacketPre-terminated with durable Low Loss MPO connectors and ready for deploymentSnap-in strain-relief clips provide easier cable managementEvery termination is tested to ensure the quality in network performanceOur proprietary manufacturing processes and advanced technology result in quality guarantee
- Durable Plug and Play Low Loss non-pinned MPO/female Connectors | Type-B Polarity (Key Up to Key Up)
- Cable made with Industry-leading Corning ClearCurve Laser-optimized Multimode OM3 50/125 Fiber and UL Certified Fire Retardant Plenum OFNP Cable Jacket | UL Certified Fire Retardant Plenum Cable Compound Materials
- High Quality 12-core Fibers | 0.20dB Typical Insertion Loss | 0.35dB Max Insertion Loss | 7.5mm Minimum Bend Radius
- For 40G/100G QSFP+/QSFP28 Direct Connection, 10G/40G/100G High-density Structural Fiber Cabling | MPO/MTP Compatible Cabling System | Patch Panel Cabinet, FTTH, EPON Application | High-density Data Centers
- High Quality Guarantee: 100% Inspection and Test on Insertion Loss and Return Loss
| Color | Aqua OM3 MPO - 1 Pack |
|---|---|
| Model | SpeedyFiberTX-12Fiber-MPO |
| Brand Name | SpeedyFiberTX |
| Cable Type | Fiber Optic |
| Item Shape | Round |
| Model Name | SpeedyFiberTX 12Fiber MPO |
| Unit Count | 1 Count |
| Manufacturer | SpeedyFiberTX |
| Connector Type | LC |
| Number of Pins | 12 |
| Outer Material | Low-smoke PVC or equivalent fire-resistant plastic |
| Number of Items | 1 |
| Connector Gender | Male-to-Female |
| Specification Met | ul certified |
| Compatible Devices | QSFP+/QSFP28 Modules, Patch Panels, Cabinets, FTTH, EPON Applications, High-density Data Centers |
| Data Transfer Rate | 1 Gigabits Per Second |
| Indoor Outdoor Usage | Indoor, Outdoor |
| Customer Package Type | rigid box |
| Compatible Phone Models | No Compatible Phone Models |
| Ethernet Cable Category | Cat 8 |
| Recommended Uses For Product | High-speed network infrastructure, data centers, and fiber optic communication systems |
| Other Special Features of the Product | Lightweight |
